RR QAV-PRO Lifter 13" 12s is a special RR BNF version based on QAV-PRO Lifter from Cinequads Edition frame, with custom new longer arms and motor mounts to allow 13" props with XNOVA 4320 350kv motors, very versatile, portable and powerful rig designed for pro cinematic shots carriyng up to 6-7 KG payload.
BNF weight (without lipos/payload) : 5,1kg
Size (without props): 58 x 45 x 25 cm
Size (with props): 86 x 69 x 25 cm
The Lumenier QAV-PRO Lifter Cinequads Edition RTF Drone is a revolutionary FPV X8 Cinelifter drone that is designed to carry professional grade Cinema Cameras while maintaining the speed and agility that characterizes a true FPV drone.
The QAV-PRO Lifter drone is engineered to take performance, versatility and creativity to the next level while making a statement with a modern and professional aesthetic. It is a must-have creative tool for every drone Cinematographer.
With the ability to carry cinema cameras at 100mph+, the QAV-PRO Lifter is the ultimate Cinema Drone when it comes to maneuverability of Heavy Cameras such as the RED KOMODO 6K, and it has outstanding performance under even the most challenging conditions.
With the QAV-PRO Lifter you can unleash your creativity and break the boundaries of conventional film making. Imagine diving down a skyscraper at breakneck speeds, pursuing a high-speed car chase closer than ever before, capturing the impossible shot or transition that you could only dream of! All of this is now possible with the Lumenier QAV-PRO Lifter drone as the performance platform behind your flying Cinema Camera.
Features
Robust T-style arm design with dual CNC Aluminum mounts that reinforce the structure, octagonal carbon fiber tubes with aluminum mounts that secure them with strong clamping force and hide internal motor and led wiring.
Cinema camera fixed to an isolation plate with 6 alpha gel a-1 dampers, combined with the battery sitting on this plate, adding damping weight and reducing vibrations.
Camera and battery position shift options, to be able to distribute the weight and balance the aircraft when using different lenses, gimbal, etc.
Optimized dual antenna placement provides maximum video performance by locating the receiving antennas away from the Cinema Camera body to guarantee signal strength.
Dedicated power management PDB for cleaner soldering to 4-in-1 esc and accessories, as well as redundancy connections to the power train system to prevent a crash during any type of malfunction.
32-degree Angled arms lower the center of gravity to the cinema camera improving payload balance and flight performance.
Motors mounted with -3 degrees of camber angle increases the authority and stability on the Yaw axis.
Proprietary LED system located on the arm ends that works with Betaflight configuration, gives the option to program light codes as a safety feature and requirement when working on set.
Cinema camera has 60 degrees of motion in 7.5-degree increments, the tilt goes from 40 degrees to -20 degrees for any type of shot needed.
The cinema camera is secured to a carbon fiber plate, which uses universal mounting slots and holes for camera versatility.
A reversable isolation plate gives the option to have the cinema camera look back for any reverse shots.
Micro-USB or USB-C extension cables for easy access to the flight controller when needing to change settings without disassembling the drone.
Included components:
ESC: APD 120F3 12s ESC.
PDB: 2 x APD PDB 500a
FC: BrainFPV Radix V2
Custom RR Arms and motor mounts to allow 13" props and XNOVA 4320 motors.
Motors: XNOVA 4320 350kv Cinelifter Line
Props: HQ 13x9x3
HD Video system: DJI HD Air Unit + TrueRC Antennas
Receiver: Crossfire Diversity Nano Rx
Gps: Matek M8Q-5883
AS150 Connectors
Vifly Finder 2 - Buzzer
Castle Creations BEC 2.0 / KDE 12v 10a - Onboard dedicated 12v to power any camera.
Recommended Lipo: 6s 4500/5100/6000+ Tattu R-Line 1.0 95c (The bigger the better) ( 2 to 4 lipo packs)
BNF weight: 5kg
RR QAV-PRO Lifter BNF includes a complete drone build, tuned and tested.
Production lead time + worldwide shipping usually between 2 to 6+ weeks.
Please contact us for more info or updated delivery/production lead time information.
